Hydrogen specific valve

Brand：Pneumatic eccentric butterfly valve 型號：WJ40F

The R hydrogen dedicated valve is a high-performance control device designed for the special physical and chemical properties of hydrogen, such as low density, flammability, explosiveness, and easy leakage.
1、 Core technical characteristics
Ultra low leakage sealing technology
By adopting a molecular level sealing structure (such as the sealing ring and protrusion designed by Chenchen Green Energy patent), the leakage rate can be controlled within ≤ 1 × 10 ⁻⁶ mbar · L/s
Multiple sealing designs (such as Tress' patented hard alloy overlay welding+pad pressure sealing) enhance valve port wear resistance
Material anti hydrogen embrittlement treatment
The main material is selected from 316L stainless steel, nickel based alloys (such as Inconel 625), or specially treated aluminum alloys
Priority should be given to hydrogen compatible fluororubber (FKM) or metal seals as sealing materials
Security protection design
Integrated static elimination device (conductive coating/grounding) to prevent spark risk
Some valves are equipped with safety relief devices (such as safety valves for pressure reducing valves)
2、 Typical product types
Valve Type Applicable Scenarios Representative Models Key Parameters
Zero leakage track ball valve hydrogen storage and transportation system Chenchen Green Energy patented valve pressure resistance 16MPa, leakage rate ≤ 10 ⁻⁶ mbar · L/s
Hydrogen pressure reducing valve hydrogen refueling station/laboratory W21.8-LH (F) input pressure 10000 Psig, temperature -40~230 ℃
High pressure solenoid valve industrial pipeline Pfeiffer detection system working pressure 360bar, leakage rate detection accuracy 10 ⁻⁶ mbar · L/s
3、 Mainstream application areas
Hydrogen refueling station
Ball valves that require quick opening and closing (full bore design) with electric actuators, with a response time of less than 1 second
Chemical equipment
Corrosion resistant regulating valves (such as Tresto heavy seal valves) are used for controlling the reaction vessel medium
Laboratory gas supply system
Precision pressure reducing valves (such as the German NOOK YK43F series) achieve stable pressure output
